This machine is easy to operate, reliable in performance, technologically advanced, and easy to maintain and upkeep

This machine is mainly used as a specialized equipment for cutting aluminum door and window corner code profiles, and can also be used for cutting and cutting thick, elongated curtain wall profiles and plastic profiles

The cutting tool adopts imported hard alloy saw blades, which have high cutting speed, high productivity, and high machining accuracy

The feed motion pair of this machine adopts linear motion bearings, which have low motion resistance and high precision

The feeding mechanism adopts an automatic feeding system, which is stable, reliable, and efficient

Adopting imported PLC programmable control system and digital display device

Suitable for mass cutting production of aluminum doors, windows, and plastic profiles

High degree of automation, work clamping, saw blade advance and retreat controlled by pneumatic system, easy to operate, safe and reliable, high productivity.

Technical parameters:

Saw blade diameter: 450mm

Backward speed: 0-3 m/min

Working speed: 0~3 m/min

Automatic cutting length: 5-500mm

Sawing width X height: 150x300

Input power: 3kw

Gas consumption: 200L/min

Host dimensions: 1900X1700X1200mm

Power supply: 380V/50Hz

Environmental temperature: 15~40 ℃

Gas source pressure: 0.5~0.8Mpa

Weight: 850Kg
